Close Coupled Toilets

Close coupled toilets pair the cistern and pan as one neat unit. They are the most familiar toilet style in UK homes. Choose from rimless, comfort height, open back, and closed back designs. Enjoy free delivery on orders over £50 and see the range in person before you buy at our Birmingham showroom.

Clear All
Filter & Sort
Clear All
Showing 16 of 16
Sort By
Filter & Sort
Clear All
Showing 16 of 16
Sort By
Kairo rimless close coupled toilet with slim square soft close seat in a modern bathroom with oak floor
Tonik close coupled open back toilet in white with soft close seat in a green tiled bathroom
47% OFF
Charlie Comfort Height Rimless Close Coupled Toilet
Eva Close Coupled Rimless Toilet
Tonik Close Coupled Closed Back Toilet with Soft Close Seat
20% OFF
Laverne Rimless Close Coupled Toilet
Carolina close couple pan in comfort height with rimless open back design, white modern toilet
Sold Out
Legend Close Coupled Traditional Toilet
20% OFF
Charlie Close-Coupled Open Back Toilet
Ashford close couple pan in standard fully enclosed white, clean design with concealed pipework
Sold Out
Sullivan Standard Height Close Coupled Square Toilet
Alessio Black Close-Coupled Toilet
Charlie Comfort Height Rimless Close Coupled Toilet

What is a close coupled toilet?

A close coupled toilet has its cistern sitting directly on the back of the pan, bolted together to form one unit. There’s no separate flush pipe, so water passes straight from cistern to pan. It stands on the floor with the cistern on show, so there’s no boxing in or frame to build. That makes it the simplest swap for most existing floor standing toilets. If you prefer a hidden cistern, see our back-to-wall and wall-hung toilets.

Types of close coupled toilets

Every close coupled toilet shares the same cistern-on-pan layout. The differences are in the bowl, the height, and how the back of the pan is finished.

  • Rimless close coupled toilets: There’s no inner lip around the bowl, so bacteria have nowhere to build up and cleaning is quicker.
  • Comfort height close coupled toilets: The pan sits a few centimetres higher than standard so sitting down and standing up take less effort.
  • Open back close coupled toilets: The back of the pan is left open, so the waste pipe connection shows. These are often lower-priced and more forgiving with existing pipework.
  • Closed back close coupled toilets: A fully enclosed pan hides the waste pipe for a cleaner look. With no gaps behind it, there’s less dust to wipe away at the base.

Close coupled toilet dimensions

Most close coupled toilets measure roughly 350mm to 400mm wide, 600mm to 700mm deep from the wall, and 750mm to 850mm tall to the top of the cistern. Sizes vary by model, so check the dimensions on each product page. To measure, check the width of your space and the depth from the back wall to any door or fixture in front. Then find the centre of your waste pipe and measure its distance from the wall (the set-out). Closed back pans need this to match closely.

How to fit a close coupled toilet

Fitting a close coupled toilet is a manageable job if you’re comfortable with basic plumbing. Here’s how it usually goes.

  1. Turn off the water at the isolation valve, flush to empty the cistern, and disconnect the supply. Unbolt the old toilet and lift it away.
  2. Check your waste pipe is clean and undamaged, then fit a new pan connector to the outlet of the new pan.
  3. Fit the flush valve and the close coupling washer (the rubber seal between cistern and pan) to the cistern. Bolt the cistern onto the pan, tightening each side a little at a time. Overtightening can crack ceramic.
  4. Push the pan connector onto the waste pipe and set the toilet in place. Check it’s level, mark the fixing holes, then drill and screw the pan to the floor.
  5. Reconnect the water supply through the isolation valve, turn it on, and let the cistern fill. Flush several times and check the cistern bolts, the washer, and the pan connector for leaks.
  6. Run a bead of silicone around the base and fit your toilet seat.

Always follow the fitting instructions that come with your toilet, as fixings and flush mechanisms vary. If you’re not sure about the pipework, or need to move the waste, we recommend hiring a qualified plumber. A badly seated connector can leak slowly under the floor for weeks before you spot it.

See our close coupled toilets at our Birmingham showroom

Want to check the height, the bowl shape, or how a soft close seat feels before you buy? Visit our Birmingham bathroom showroom at 15 Seeleys Road, Tyseley, B11 2LQ. Explore our full range of close coupled toilets in person alongside our full bathroom range, and our team can talk through sizes and pipework. We’re open seven days a week.
