Back to Wall Toilets

Our back-to-wall toilets hide the cistern inside a furniture unit or stud wall, so all you see is a neat pan sitting flush to the wall. Choose from rimless, comfort height, square, and round designs, with free UK delivery over £50. Or see our range of back-to-wall toilets for yourself in our Birmingham showroom.

Clear All
Filter & Sort
Clear All
Showing 9 of 9
Sort By

What is a back to wall toilet?

A back-to-wall toilet is a floor-standing pan that sits flush against the wall with no visible cistern. The cistern is hidden behind it, either inside a toilet unit or behind a boxed-in stud wall. You flush with a button or lever on the unit or wall. A back-to-wall toilet creates a tidier finish as there’s no gap behind the pan for dust to collect, which makes it easy to wipe down.


Do back to wall toilets come with a cistern?

Usually, no. Most back-to-wall toilets are sold as the pan, often with a soft-close seat, so you’ll need a concealed cistern to go with it. Check each product page to see what’s in the box. You’ll also need somewhere to hide the cistern. That can be a back-to-wall toilet unit, a toilet and sink combination unit, or a false wall built over a frame.


Types of back to wall toilets

Every back-to-wall toilet hides the cistern. The pans themselves vary in shape, height, and how easy they are to clean.

  • Back-to-wall rimless toilets have no inner lip around the bowl, so there’s nowhere for grime to build up. A quick wipe keeps them hygienic.
  • Back-to-wall comfort height toilets sit higher than standard pans. They’re easier to sit down on and stand up from, which suits older and taller users.
  • Back-to-wall short projection pans stick out less from the wall. They free up floor space in cloakrooms, en suites, and other small bathrooms.
  • Back-to-wall traditional toilets bring period shaping to a hidden-cistern design. You get a classic look without an exposed cistern on show.


If you’re not sure which type will suit your bathroom, our toilet buying guide covers each option in more detail.


What sizes do back to wall toilets come in?

Most back-to-wall toilets are around 350mm wide and project 480mm to 560mm from the wall. Standard pans sit roughly 400mm high. Comfort height models are taller. Leave enough room in front of the pan to sit comfortably and remember to allow for the depth of your unit or false wall too. Each product page lists exact dimensions.


How to fit a back to wall toilet

Fitting a back-to-wall toilet takes more planning than a standard toilet because the cistern and pipework end up hidden. Here’s how it works:

  1. Plan the position first. Your pan’s waste outlet needs to line up with the soil pipe, so check where the soil pipe and water supply sit before anything else.
  2. Build the concealment. Fit a support frame with the concealed cistern, or assemble your toilet unit, following the manufacturer’s instructions.
  3. Connect the water supply to the cistern’s inlet valve. Add an isolation valve so you can turn the water off for maintenance.
  4. Connect the pan. Push the pan connector onto the soil pipe, attach the flush pipe from the cistern, then fix the pan to the floor with the fixings supplied.
  5. Fit the unit front or wall panel and the flush button. Then seal the base with silicone, fit the seat, and run a few test flushes to check for leaks.


If you're not confident with plumbing, we recommend hiring a qualified plumber or bathroom fitter. A leak behind a boxed-in wall can go unnoticed for a long time and damage your floor before you spot it. Ask them to leave an access panel so the cistern can be reached later.

See our back to wall toilets at our Birmingham showroom

If you prefer to see our back-to-wall toilets in person before you make your decision, our showroom at 15 Seeleys Road, Tyseley, has over 180 bathrooms on display and is open seven days a week. Compare our back-to-wall toilets side by side with the help of our expert team.
